Günter Grossmann GT1700
Also listed as GT 1700
1,700 kg3,748 lbOperating weight
Yanmar 3TNV70DieselEngine
10.3 kW13.8 hpEngine power
1,980 mm6 ft 6 inDig depth
960 mm37.8 inWidth
3,640 mm11 ft 11 inReach
Check your machine plate before ordering parts. How to find it
Parts 0
No part numbers recorded yetSend a photo of the part and your machine plate and we'll help identify it.
Fix a problem 5
Cranks but won't startFuel filter, glow plugs, safety lever
Hydraulics slow or weakFluid, filters, relief valve
Cold-weather startingBattery, fuel gelling, warm-up
Tracks keep coming offTension, idlers, sprockets
Upper won't swing or clunksSwing motor bolts, gear, grease
All troubleshootingSpecifications
- Engine
- Yanmar 3TNV70 10.3 kW (13.8 hp)
- Boom swing
- 51°/55°
- Operating weight
- 1,700 kg (3,748 lb)
- Engine power
- 10.3 kW (13.8 hp)
- Max digging depth
- 1,980 mm (6 ft 6 in)
- Max digging reach
- 3,640 mm (11 ft 11 in)
- Overall width
- 960 mm (37.8 in)
- Expanded track width
- 1,260 mm (4 ft 2 in)
- Bucket capacity
- 0.03 m³ (1.06 cu ft)
- Hydraulic flow
- 22 L/min (5.8 US gal/min)
- Working pressure
- 16 MPa (2,321 psi)
- Boom swing left
- 51°
- Boom swing right
- 55°
- Track size
- 230 mm (9.1 in) wide
- Published price
- 48,000 PLN net
Similar & related machines
No closely related machines recorded yet.
Mods for the GT1700
All modsOperator cooling fanAdd a 12 V fan to move engine heat and fumes away from the seat.Fuel tank relocation & extra capacityMove a hard-to-reach tank or add capacity so you refuel less often.ThumbAdd a mechanical or hydraulic thumb to pick up rocks, logs and debris.Quick hitchSwap buckets and attachments in minutes instead of driving pins.Seat upgradeSwap the thin factory seat for a padded or suspension seat with a lap belt.LED work lightsAdd work lights for early starts, late finishes and dark sheds.
