Minidiger MD-2
Also listed as Minidiger MD2, Mini Diger MD-2, МД-2, Мінідігер МД-2, Минидигер МД-2
500 kg1,102 lbOperating weight
6 hp4.5 kWEngine power
1,700 mm5 ft 7 inDig depth
1,340 mm4 ft 5 inWidth
160 bar2,321 psiWorking pressure
1,700 mm5 ft 7 inHeight
Check your machine plate before ordering parts. How to find it
About the MD-2
The MD-2 is a towable excavator with hydraulic front stabilisers. Its headline dimensions match the MD-1, but its stabiliser arrangement differs.
Specifications and design details: Minidiger manufacturer catalogue, checked 16 October 2026. Differences from seller listings are noted above.
Fix a problem 6
Cranks but won't startFuel filter, glow plugs, safety lever
Hydraulics slow or weakFluid, filters, relief valve
Cold-weather startingBattery, fuel gelling, warm-up
Tracks keep coming offTension, idlers, sprockets
Upper won't swing or clunksSwing motor bolts, gear, grease
Jerky or twitchy controlsThrottle, springs, flow controls
All troubleshootingSpecifications
- Machine weight
- 500 kg (1,102 lb)
- Overall width
- 1,340 mm (4 ft 5 in)
- Overall height
- 1,700 mm (5 ft 7 in)
- Overall length
- 2,400 mm (7 ft 10 in)
- Max digging depth
- 1,700 mm (5 ft 7 in)
- Engine power
- 6 hp (4.5 kW)
- Engine
- Four-stroke diesel
- Boom swing
- 180°
- Working pressure
- 160 bar (2,321 psi)
- Country of manufacture
- Ukraine
- Machine type
- Towable excavator
